Product Description:

Apollo LED street light series are Kingsun recently newly released most complete and most functional road lighting in the industry, embracing the typical Europe and America solid and slim style, flexible current driving range, thermal and optical integrated modular system, multi-options of light distribution, free tool installation and maintainence,full solution with wide range applicable installation inter-face and various control methods.

Product Characteristics:

1.Applied with top grade LED from Cree or Lumileds

2.Non-image optics system, improves lumen output ratio

3.Modular design, carrying big range from power from 30W to 240W

4.High efficiency driver system from Philips/Advance

5.Luminaire efficiency up to 90 lm/W ± 3lm

6.Open air ventilation design, good heat dissipation function

7.Innovative and unique design of rotating arm branch, tilt -30 to 90 degree adjustable, compatible with the interface Φ60 and below, fit the purpose of the change or upgrade of conventional road lighting.

8.”Tool free” locking design to open and close the driver compartment simply, easy installation and maintainance.

s:

1. Aluminum alloy housing and electrostatic sprayed surface reaches good resistance to corrosion, complying with RoHS standard.

2. Built-in chimney effect thermal management system can solve the decrease of heat dissipation ability caused by dirt retention.

3. Modular structure could be applied for power variation by module increase and decrease.

4. Glare-less lighting with Patented light distribution technology, safe for driving.

5. Fast plug-in-out connector ensures much easier maintenance.

Application

High Mast, Tunnel, Gas Station.

• Description

Features

●Simple appearance with classic black and white color match providing a comfortable vision.

●Immune to harsh environment with anti-corrosion aluminum materials.

●Built-in chimney effect thermal management system, solving the problem of heat dissipation ability decrease caused by dirt retention.

●Patented modular structure to realize power serialization by changing module Qty.

●High luminance, uniform and soft light prevents visual fatigue.

●Approval with CE and UL certifications, up to 5 years warranty.

●Flexible application for various spaces with ceiling installation.

• Description

Description

• Aluminum alloy, high corrosion resistance and weather-resistance
• Built-in chimney effect thermal management system with self-cleaning function and reliable performance.
• Patented removable-Modules design for power variation.
• Flexible drive allocation options for different regions.

Description

■ Elegant esthetic appearance.
■ Die cast aluminum housing and high quality driver enhance life span of fixture.
■ Surge protection device included.Electrical class I or Class II
■ Compact size, easy to transport and install.
■ 3 sizes and 10 wattages 23,33,47,75,90,110,130,155,180 and 200 Watt.
■ NEMA 3 or 7 pin optional.
■ Daylight sensor, Photocell and wireless control optional.

Applications
Alleys, Walkways, Parks and Gardens.

Product Description:

Super industrial design, streamline and elegant appearance.
■ Adopt modular design with compact structure, lightness for easy maintenance.
■ Circular module with surface self-clean function.
■ Light distribution precision, high utilization of light, more energy saving.
■ Lightning surge prevention system ensures reliability and stability.

• Description

Description

Miniature Circuit Breakers for use in domestic installations, as well as commercial and industrial distribution systems.

• Short circuit protection
• Overload protection
• Switch
• Isolation
• Contact position indicator
• 10kA breaking capacity
• Rated current- 63,80,100,125
• Poles-1P,2P,3P,4P

1.1 Function

protection of circuits against short-circuit currents,protection of circuits against overload currents,switch,isolation.

1.2 Selection

Technical data of the network at the point considered:the earthing systems (TNS, TNC),short-circuit current at the circuit-breaker installation point, which must always be less than the breaking capacity of this device,network normal voltage.

Tripping curves:

B curve (3-5In)

protection for people and big length cables in TN and IT

systems.

C curve (5-10In)

protection for resistive and inductive loads with low inrushcurrent.

D curve(10-20In)

protection for circuits which supply loads with high inrush current at the circuit closing

(LV/LV transformers, breakdown lamps).

Overview

NM8
Application:               LV moulded case circuit breaker with adjustable release,
                           LV moulded case circuit breaker with inteligent release (S)
Poles:                     1, 2, 3, 4
Short-circuit capacity:    up to 150kA
Nominal voltage:	   690V AC
Nominal current:	   16  ..  1600A
Standard:                  IEC/EN 60947-2

General

• Rated current from 10 to 1250A
• Employing a fixed thermal and fixed magnetic trip
• Frames made of rigid material of engineering plastics
• Complete range of  one, two, three and four pole version
• 4-class breaking capacity from 10kA to 70kA
• Vertical/horizontal installation
• Circuit Breaker and auxiliaries comply with the following internation Standard: IEC/EN60947-2 (General rules-circuit breakers)
• Automatic control components
• Certified for operation in pollution-degree III environments as defined by IEC standard 60947 (industrial environment)
• Temperature range from -5 to +40 degree celcius
• A complete system of add-on modules for NM1
• Certificates: KEMA, UKrSEPRO, EAC, RCC, EK
